Technical Specifications
| Model | ZBZD450X2 | ZBZD700 |
| Production Lines | 2 Lines | 1 Line |
| Maximum Film Width | 200–400 mm / 300–600 mm | 300–600 mm |
| Reel Bag Width | 300 mm | |
| Bag Length | 300–1000 mm | 1000–1500 mm |
| Film Thickness | 7–35 μm per layer | |
| Production Speed | 80–100 m/min | |
| Output Speed | 180–300 pcs/min | 100–250 pcs/min |
| Maximum Reel Diameter | 900 mm | |
| Air Compressor | 3 HP | |
| Total Power | 15 kW | 12 kW |
| Machine Size | 6500 × 1800 × 1900 mm | 6500 × 1500 × 1900 mm |
| Weight | 3500 kg | 3000 kg |
Automatic Roll Bag Making Machine for Bag on Roll Production
The roll bag making machine is designed for producing plastic bags on roll, widely used in supermarkets, food packaging, retail, and industrial applications. It supports both core and coreless roll bag production.
This bag on roll making machine features automatic film cutting, core changing, and continuous rewinding, helping manufacturers improve production efficiency while reducing labor and energy consumption.
Equipped with a dual servo motor control system, the machine ensures stable performance and precise bag forming. It is suitable for producing both printed and non-printed bags with consistent sealing quality.
For buyers searching for a plastic roll bag making machine or core roll bag production equipment, this machine provides a flexible solution with both dual-line and single-line configurations to meet different production requirements.
The ZBZD450X2 and ZBZD700 models are widely used for producing bottom-sealed bags and back cover printed bags on rolls, making them suitable for various packaging markets.
Applications of Roll Bag Making Machine
This machine is widely used for producing plastic bags on rolls for different industries and packaging applications.
- Supermarket roll bags
- Food packaging bags on roll
- Garbage bags on roll
- Retail packaging bags
- Core and coreless roll bags
- Printed plastic roll bags
Machine Running Video
Roll Bag Making Machine Questions
What is a roll bag making machine?
It is a machine used to produce plastic bags connected in rolls for easy tearing and packaging.
What is the difference between core and coreless roll bags?
Core roll bags use a paper or plastic core, while coreless bags are rolled without a core to reduce material cost.
Can this machine produce printed bags?
Yes, it supports both printed and non-printed film production.
What industries use roll bags?
Roll bags are widely used in supermarkets, food packaging, retail, and industrial applications.
Is dual-line production available?
Yes, the ZBZD450X2 model supports dual-line production for higher output efficiency.
