Technical Specifications
| Parameter | ZBR180C-260 | ZBR180C-330 | ZBR180C-420 | ZBR180C-520 |
|---|---|---|---|---|
| Max. Web Width | 274 mm | 350 mm | 440 mm | 540 mm |
| Max. Printing Width | 254 mm | 330 mm | 420 mm | 520 mm |
| Max. Machine Speed | 180 m/min | |||
| Max. Printing Speed | 160 m/min | |||
| Max. Unwind / Rewind Dia | Φ40" / Φ1000 mm | |||
| Drive Type | Gear Drive | |||
| Photo Polymer Plate | To Be Specified | |||
| Ink | Water Base Ink or Solvent Ink | |||
| Printing Length (Repeat) | 280 – 600 mm | |||
| Range of Substrates | Films 30–100 gsm, Paper 80–250 gsm, Cardboard 100–350 gsm | |||
| Electrical Supply | Voltage 380V, 50Hz, 3PH or to be specified | |||
| Parameter | ZBR180C-650 | ZBR180C-830 | ZBR180C-920 | ZBR180C-1000 |
|---|---|---|---|---|
| Max. Web Width | 670 mm | 870 mm | 940 mm | 1020 mm |
| Max. Printing Width | 600 mm | 830 mm | 900 mm | 980 mm |
| Max. Machine Speed | 180 m/min | |||
| Max. Printing Speed | 160 m/min | |||
| Max. Unwind / Rewind Dia | Φ60" / Φ1500 mm | |||
| Drive Type | Gear Drive | |||
| Photo Polymer Plate | To Be Specified | |||
| Ink | Water Base Ink or Solvent Ink | |||
| Printing Length (Repeat) | 282.6 – 901.7 mm / 301.6 – 1200.1 mm | |||
| Range of Substrates | Films 30–100 gsm, Paper 80–250 gsm, Cardboard 100–350 gsm | |||
| Electrical Supply | Voltage 380V, 50Hz, 3PH or to be specified | |||
| Parameter | ZBR180C-1100 | ZBR180C-1300 | ZBR180C-1450 | ZBR180C-1600 |
|---|---|---|---|---|
| Max. Web Width | 1120 mm | 1310 mm | 1470 mm | 1620 mm |
| Max. Printing Width | 1080 mm | 1250 mm | 1410 mm | 1590 mm |
| Max. Machine Speed | 180 m/min | |||
| Max. Printing Speed | 160 m/min | |||
| Max. Unwind / Rewind Dia | Φ60" / Φ1500 mm | |||
| Drive Type | Gear Drive | |||
| Photo Polymer Plate | To Be Specified | |||
| Ink | Water Base Ink or Solvent Ink | |||
| Printing Length (Repeat) | 282.6 – 901.7 mm / 301.6 – 1200.1 mm / 301.6 – 1597.02 mm | |||
| Range of Substrates | Films 30–100 gsm, Paper 80–250 gsm, Cardboard 100–350 gsm | |||
| Electrical Supply | Voltage 380V, 50Hz, 3PH or to be specified | |||
Inline Flexo Printing Machine for Paper Packaging and Carton Printing
The ZBR180C inline flexographic printing machine is designed for high-efficiency printing of paper packaging materials such as paper cups, paper bags and folding cartons. The inline structure allows multiple printing units to operate sequentially, providing stable printing performance and flexible color configuration.
With a maximum machine speed of 180 m/min and printing speed up to 160 m/min, the ZBR180C series is suitable for packaging manufacturers producing paper packaging products in high volumes.
High Precision Printing System
The machine integrates advanced plate mounting systems and automatic registration technology to ensure precise color alignment and consistent printing quality.
Flexible Printing for Paper Packaging Production
The inline flexo press supports a wide range of paper and cardboard substrates used in paper cups, paper bags, food packaging and folding cartons.
Efficient Production and Reduced Waste
Automatic pre-registration and closed-loop tension control systems help reduce paper waste during machine setup while maintaining stable printing quality.
Reliable Printing Solution for Packaging Manufacturers
The ZBR180C flexographic printing machine provides a cost-effective printing solution for packaging converters looking for efficient and scalable paper packaging production.
Applications in Paper Packaging and Label Printing
The ZBR180C inline flexographic printing machine is designed for high-efficiency printing on paper, cardboard and flexible packaging materials. It is widely used in paper packaging production lines including paper cups, paper bags, folding cartons and food packaging products.
-
Paper Cup Printing
Suitable for printing paper cups and paper bowl materials used in beverage and food packaging industries. -
Paper Bag Printing
Used for printing kraft paper bags, shopping bags and takeaway food packaging bags. -
Folding Carton Packaging
Applicable for printing folding cartons used for pharmaceuticals, cosmetics and consumer goods packaging. -
Food Packaging Paper
Designed for printing hamburger paper, snack wrap paper and other food-grade packaging paper. -
Label and Packaging Printing
Suitable for printing labels, packaging graphics and promotional packaging materials.
Label Printing
- Application: High-quality label printing on paper substrates.
- Label Types: Food labels, beverage labels, alcohol labels, pharmaceutical labels, cosmetics labels.
- Substrate Range: Paper 20–100 gsm, 80–200 gsm and 150–350 gsm.
- Industries: Food, beverage, pharmaceutical, health and beauty, logistics labeling.
Folding Carton Printing
- Application: Pre-printing on paperboard used for folding carton packaging.
- Material Thickness: Paperboard 100–300 gsm.
- Typical Products: Beverage cartons, alcohol packaging boxes, home appliance packaging and express cartons.
- Advantage: High-speed inline printing with stable color registration.
Paper Packaging Printing
- Application: Printing for various paper packaging materials.
- Paper Range: 60–400 gsm paper substrates.
- Packaging Types: Paper cups, paper plates, paper boxes, cartons and kraft paper bags.
- Industries: Food packaging, garment packaging, pharmaceutical packaging.
Film / Aluminium Foil Printing
- Application: High-speed flexographic printing on plastic films and aluminium foil packaging.
- Material Range: Films 20–100 gsm and flexible packaging substrates.
- Packaging Uses: Food packaging films, beverage packaging, pharmaceutical foil packaging.
- Benefit: Stable high-speed printing suitable for roll-to-roll flexible packaging production.
Machine Running Video
Frequently Asked Questions
What is an inline flexo printing machine?
An inline flexo printing machine arranges multiple printing units in a straight line, allowing each printing color to be applied sequentially. This design enables high productivity and easy integration with packaging converting equipment.
What materials can the ZBR180C flexo press print?
The machine supports paper, cardboard and plastic films used in packaging production such as paper cups, paper bags and folding cartons.
What is the maximum printing speed?
The ZBR180C inline flexographic printing press has a maximum machine speed of 180 m/min and printing speed up to 160 m/min.
What industries use inline flexo printing machines?
Inline flexo presses are widely used in food packaging, paper packaging, folding carton printing and label printing industries.
What are the advantages of inline flexo printing machines?
Inline flexo presses provide stable printing quality, flexible color configuration and easy integration with converting equipment such as die cutting and slitting systems.
