Technical Specifications
| Parameter | ZBR300S-CI8-600 | ZBR300S-CI8-800 | ZBR300S-CI8-1000 | ZBR300S-CI8-1200 |
|---|---|---|---|---|
| Max. Web Width | 700 mm | 900 mm | 1100 mm | 1300 mm |
| Max. Printing Width | 600 mm | 800 mm | 1000 mm | 1200 mm |
| Max. Machine Speed | 300 m/min | |||
| Max. Printing Speed | 280 m/min | |||
| Max. Unwind / Rewind Diameter | Φ800 mm / Φ1200 mm | |||
| Drive Type | Central Drum with Gear Drive | |||
| Photo Polymer Plate | To Be Specified | |||
| Ink Type | Water Based Ink or Solvent Ink | |||
| Printing Length (Repeat) | 350 – 900 mm | |||
| Range of Substrates | LDPE, LLDPE, HDPE, BOPP, CPP, PET, Nylon, Breathable Film | |||
| Electrical Supply | 380V, 50Hz, 3 Phase (Customizable) | |||
Sleeve Type CI Flexo Printing Machine for Thin Film Flexible Packaging
The ZBR300S CI flexo printing machine is an advanced sleeve type central impression flexographic printing press designed for high-quality printing of thin-film flexible packaging materials such as PP, PE, CPP and BOPP. It combines the high stability of the central impression structure with the efficiency and flexibility of sleeve type technology.
With a maximum machine speed of 300 m/min and a maximum printing speed of 280 m/min, the ZBR300S series is a practical solution for packaging manufacturers who need stable color registration, efficient production and reliable print quality on flexible packaging materials.
Sleeve Type Technology for Faster Changeover
The sleeve type design improves production flexibility by simplifying changeover and reducing downtime during job switching. This is especially useful for converters handling multiple packaging orders and different repeat lengths.
Stable Central Impression Printing Performance
The central impression structure helps maintain stable web handling and consistent printing pressure, which is especially important for thin films such as PP, PE, CPP and BOPP. This allows the machine to deliver reliable print quality and accurate color registration during continuous production.
Wide Material Compatibility for Packaging Production
The ZBR300S flexographic printing machine can process LDPE, LLDPE, HDPE, BOPP, CPP, PET, nylon and breathable films. It is also suitable for paper, non-woven materials, aluminium foil and related packaging converting applications, helping converters expand their product range.
Efficient Production with Practical Automation Functions
The machine is equipped with pre-registration, production menu memory, automatic clutch pressure at start-up and shut-down, automatic pressure adjustment during speed increase, chamber doctor blade ink supply, centralized drying and cooling after printing. These functions help reduce waste, improve consistency and simplify operation.
Suitable for Flexible Packaging, Paper and Non-Woven Applications
The ZBR300S sleeve type CI flexo press is widely used for food packaging, beverage labels, paper cups, paper plates, cartons, kraft paper bags, medical packaging, diaper wet bags, e-commerce packaging, industrial transportation packaging and non-woven bag printing. It is a versatile solution for converters serving multiple packaging markets.
Applications in Flexible Packaging Printing
The ZBR300S sleeve type CI flexo printing machine is widely used for high-quality printing of flexible packaging materials such as PP, PE, CPP and BOPP films. It is suitable for a broad range of roll-to-roll applications that require stable printing, efficient production and reliable color registration.
-
Food Packaging Films
Suitable for printing snack packaging, frozen food packaging, and other flexible food-grade packaging films. -
Beverage Labels and Flexible Film Packaging
Used for printing beverage labels and packaging films requiring clear graphics and stable color consistency. -
Paper Products and Paper Packaging
Applicable for paper plates, paper boxes, cartons, paper cups and kraft paper bags used in food service and retail packaging. -
Medical, Hygiene and Daily Use Packaging
Suitable for medical packaging, diaper wet bags, and hygiene product packaging that require reliable print quality. -
E-commerce, Industrial and Non-Woven Applications
Designed for express packaging, e-commerce packaging, industrial transportation packaging and non-woven bag printing. -
Food Packaging & Cosmetics Packaging & Detergent Packaging
Designed for high-quality printing on flexible films used for food pouches, cosmetic sachets, and household detergent bags, ensuring vibrant colors and excellent resistance to chemical contents.
Food Packaging & Cosmetics Packaging & Detergent Packaging
Beverage Labels
Paper Packaging
Medical Packaging
Diaper Wet Bags
Clothing Express Packaging
E-commerce Packaging
Industrial Transportation
Non-woven Bag
Machine Running Video
Frequently Asked Questions
What is a sleeve type CI flexo printing machine?
A sleeve type CI flexo printing machine uses sleeve technology together with a central impression structure to improve printing efficiency, simplify cylinder changeover and maintain stable print quality on thin flexible packaging materials.
What is the maximum speed of the ZBR300S flexo printing machine?
The ZBR300S series has a maximum machine speed of 300 m/min and a maximum printing speed of 280 m/min, making it suitable for medium to high-speed flexible packaging production.
What materials can the ZBR300S print?
The machine is designed for PP, PE, CPP and BOPP thin-film flexible packaging materials. It can also handle film, paper, non-woven materials, aluminium foil and related converting applications.
How many printing decks are available?
The ZBR300S series can be configured with 4, 6, 8 or 10 printing decks depending on the customer’s printing requirements and production plans.
What type of ink can be used on this machine?
The machine supports both water based ink and solvent ink, allowing users to choose the appropriate ink system for different substrate types and packaging applications.
What industries use the ZBR300S CI flexo press?
The machine is widely used for food packaging, beverage labels, paper packaging, medical packaging, diaper wet bag printing, clothing express packaging, e-commerce packaging, industrial packaging and non-woven bag printing.
